K&N Custom Assembly Filter Kits, like all K&N air filters, are designed to provide excellent filtration and optimum air flow.
K&N Custom Assembly Filter Kits utilizes an adapter or tube that mounts directly to the air box. The universal clamp-on air filter then attaches to the adapter or tube. The large mounting surface of the clamp-on air filter provides better stability during rigorous riding. The assembly adapter or tube acts as a velocity stack within the air box. K&N Custom Assembly Filter Kits, like all K&N air filters, are designed to provide excellent filtration and outstanding air flow.
- Includes a custom filter adapter
- Filter clamps on to adapter
- Washable and reusable
- High air flow with excellent filtration
Information:
Associated products: 99-5000 Filter Care Service Kit Aerosol
Application Summary:
| Year |
Make/Model |
| 2011-2012 |
Can-Am Outlander 650 EFI |
| 2011 |
Can-Am Outlander 650 EFI XT |
| 2010-2011 |
Can-Am Outlander 650 EFI XT-P |
| 2010 |
Can-Am Outlander 650 HO 4x4 EFI |
| 2010 |
Can-Am Outlander 650 HO 4x4 EFI XT |
| 2009-2010 |
Can-Am Outlander 800 HO 4x4 EFI |
| 2009-2010 |
Can-Am Outlander 800 HO 4x4 EFI XT |
| 2011 |
Can-Am Outlander 800R EFI |
| 2012 |
Can-Am Outlander 800R EFI X mr |
| 2011 |
Can-Am Outlander 800R EFI X xc |
| 2011 |
Can-Am Outlander 800R EFI XT |
| 2010-2011 |
Can-Am Outlander 800R EFI XT-P |
| 2011-2012 |
Can-Am Outlander Max 650 EFI |
| 2011-2012 |
Can-Am Outlander Max 650 EFI XT |
| 2010-2012 |
Can-Am Outlander Max 650 EFI XT-P |
| 2010 |
Can-Am Outlander Max 650 HO EFI |
| 2010 |
Can-Am Outlander Max 650 HO EFI XT |
| 2009-2010 |
Can-Am Outlander Max 800 HO EFI |
| 2009-2010 |
Can-Am Outlander Max 800 HO EFI LTD |
| 2009-2010 |
Can-Am Outlander Max 800 HO EFI XT |
| 2011-2012 |
Can-Am Outlander Max 800R EFI |
| 2011-2012 |
Can-Am Outlander Max 800R EFI LTD |
| 2011-2012 |
Can-Am Outlander Max 800R EFI XT |
| 2010-2012 |
Can-Am Outlander Max 800R EFI XT-P |
| 2009-2010 |
Can-Am Renegade 800 |
| 2009-2010 |
Can-Am Renegade 800 X |
| 2010-2011 |
Can-Am Renegade 800 X xc |
| 2010-2011 |
Can-Am Renegade 800R |
| 2010-2011 |
Can-Am Renegade 800R X xc |
| Attributes |
| Air Box Included |
No |
| Air Filter Color |
Red |
| Air Filter Height |
4.625 in (117 mm) |
| Air Filter Material |
Cotton Gauze |
| Air Filter Outlet Shape |
Round |
| Air Filter Washable |
Yes |
| Alternate Part Number |
CM-8009 |
| ASIN |
B008ZE8ZXM |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Clamp Color/Finish |
Natural |
| Clamp Material |
Stainless Steel |
| Clamp Style |
Mini |
| Clamps Included |
1 |
| Color |
Red |
| Country of Origin (Primary) |
US |
| Coupler Color/Finish |
Not Applicable |
| Couplers Included |
None |
| Emission Code |
Legal US |
| Flange Inside Diameter |
3 in (76 mm) |
| Flange Length |
0.625 in (16 mm) |
| Harmonized Tariff Code (Schedule B) |
8421310000 |
| Hazardous Material Code |
N |
| Inlet Diameter |
3 in (76 mm) |
| Intake Pipe Color / Finish |
Black |
| Intake Pipe Material |
High-Density Cross-Linked Polyethylene |
| Intake Pipe Ports |
All intake tube ports needed for the specified applications are included |
| Life Cycle Status Code |
Available to Order |
| Mass Air Flow Sensor Adapter Included |
No |
| Mounting Hardware Included |
Yes |
| NAFTA Preference Criterion Code |
B |
| Oil Included |
Yes |
| Overall Height |
4.625 in (117 mm) |
| Package Material |
Paperboard |
| Package Type |
Box |
| Product Box Height |
8.69 in (221 mm) |
| Product Box Length |
8.19 in (208 mm) |
| Product Box Width |
8.13 in (206 mm) |
| Product Style |
Motorcycle Intake System |
| Replacement Filter |
None |
| SDR Required Flag |
N |
| Standard Pack |
4 |
| Top Material |
None |
| Top Style |
Rubber |
| Warranty |
1 Year Limited |
| Warranty Time |
12 |
| Weight |
1.6 lb (0.7 kg) |
| GTIN |
10024844308709 |
