K&N's easy-to-install Typhoon air intake system replaces the restrictive factory air filter and air intake tubing delivering a guaranteed power gain. The low-restriction aluminum intake tube comes in an attractive chrome-like finish.
The K&N 69-8704TP Typhoon air intake system is a free-flowing, mandrel-bent aluminum tube air induction system designed to fit some Lexus GS350 and IS350 models. The restrictive factory air filter and air intake tubing are replaced by the K&N Typhoon air intake which is designed to dramatically reduce air flow restriction as it smoothes and straightens air flow. This allows your engine to inhale a larger amount of air than the factory air intake for a guaranteed power gain. More air means more usable power and acceleration throughout the engine's RPM range. The 69-8704TP air intake comes with a replacement K&N high-flow air filter and an aluminum intake tube that easily connects to your vehicle's factory air box and throttle body. The intake tube has an attractive chrome-like finish that's made to last and it accommodates the factory crank case vent hose. The air filter can be used for up to 50,000 miles before servicing is needed depending on driving conditions. This air intake system is designed for easy installation and requires commonly available tools to do the job. ach vehicle and air intake.
- Guaranteed to increase horsepower
- Designed to improve throttle response and engine sound
- Low restriction aluminum tube
- Replaces stock air filter and intake tube
- Lasts up to 100,000 miles before service is required (depending on driving conditions)
- Easy to install with commonly available tools
- Washable and reusable lifetime air filter
- K&N Million Mile Limited Warranty
Information:
Associated products: 33-2452 Replacement Air Filter, 99-5000 Filter Care Service Kit Aerosol
Application Summary:
| Year |
Make/Model |
| 2013-2020 |
Lexus GS350 |
| 2014-2015 |
Lexus IS250 |
| 2013-2025 |
Lexus IS350 |
| 2015-2025 |
Lexus RC350 |
| Attributes |
| Air Box Included |
No |
| Air Filter Color |
Red |
| Air Filter Element Washable |
Yes |
| Air Filter Height |
1.000 in. (25mm) |
| Air Filter Material |
Cotton Gauze |
| Air Filter Oulet Length |
9.188 in. (233mm) |
| Air Filter Oulet Width |
9.000 in. (229mm) |
| Air Filter Outlet Length |
9.188 in. (233mm) |
| Air Filter Outlet Shape |
Not Flanged |
| Air Filter Outlet Width |
9.000 in. (229mm) |
| Air Filter Washable |
Yes |
| Alternate Part Number |
69-8704TP |
| ASIN |
B00MWZLCC6 |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| CARB EO Number |
D-269-52/D-269-91 |
| Clamp Color |
Natural |
| Clamp Color/Finish |
Natural |
| Clamp Material |
Stainless Steel |
| Clamp Quantity |
4 |
| Clamp Style |
Regular |
| Clamps Included |
4 |
| Country of Origin (Primary) |
US |
| Coupler Color |
Black |
| Coupler Color/Finish |
Black |
| Couplers Included |
2 |
| Emission Code |
Legal US |
| Estimated Horse Power Gain |
12.57 HP @ 5498 RPM |
| Estimated Horsepower Gain |
12.57 HP @ 5498 RPM |
| Estimated Torque Gain |
14 lbft |
| Filter Color |
Red |
| Filter Material |
Cotton Gauze |
| Harmonized Tariff Code (Schedule B) |
8421310000 |
| Hazardous Material Code |
N |
| Horse Power Increase |
13 HP |
| Intake Pipe Color |
Polished |
| Intake Pipe Color / Finish |
Polished |
| Intake Pipe Inlet Length |
16.000 in. (406mm) |
| Intake Pipe Inlet Shape |
Round |
| Intake Pipe Inlet Width |
3.000 in. (76mm) |
| Intake Pipe Material |
Aluminum |
| Intake Pipe Outlet Length |
16.000 in. (406mm) |
| Intake Pipe Outlet Shape |
Round |
| Intake Pipe Outlet Width |
3.000 in. (76mm) |
| Intake Pipe Ports |
All intake tube ports needed for the specified applications are included |
| Item Weight |
5.100 lbs. (2.3 kg) |
| Life Cycle Status Code |
Available to Order |
| Mass Air Flow Sensor Adapter Included |
No |
| Mass Air Flow Sensor Included |
Mass Air Flow Sensor Adapter Included When Required |
| Mounting Hardware Included |
Yes |
| NAFTA Preference Criterion Code |
B |
| Oil Included |
Yes, Filter Is Pre-Oiled |
| Package Material |
Paperboard |
| Package Type |
Box |
| Product Box Height |
8.5 in (216 mm), 8.500 in. (216mm) |
| Product Box Length |
18.25 in (464 mm), 18.250 in. (464mm) |
| Product Box Width |
14.5 in (368 mm), 14.500 in. (368mm) |
| Product Style |
69 Series Typhoon Kits |
| Replacement Filter |
33-2452 |
| RPM |
5498 |
| SDR Required Flag |
N |
| Standard Pack |
1 |
| Street Legal In All US States |
See Application Link Above, Not legal for sale or use in California on any pollution controlled motor vehicle. NOTE: Some specific models and years may be legal in CA. Check the CARB status on your parts at knfilters.com. |
| System Type |
Cold-Air Intake System |
| TUV Approved (Europe) |
No, No |
| Warranty |
No-Hassle Lifetime Limited |
| Weight |
5.1 lb (2.3 kg) |
| GTIN |
00024844351272 |
