K&N's easy-to-install Typhoon air intake system replaces the restrictive factory air filter and air intake housing delivering a guaranteed power gain. The low-restriction aluminum intake tube comes in a blue powder coat finish.
The K&N 69-3539TB Typhoon air intake system is a free-flowing, mandrel-bent aluminum tube air induction system designed to fit some Ford Focus models. The restrictive factory air filter and air intake housing are replaced by the K&N Typhoon air intake which is designed to dramatically reduce air flow restriction as it smoothens and straightens air flow. This allows your engine to inhale a larger amount of air than the factory air intake. More air means more usable power and acceleration throughout the engine's RPM range. The 69-3539TB air intake comes with a black rubber topped K&N high-flow air filter and a heat shield that installs using the factory mounting locations. A molded scoop funnels outside air towards the filter. Air is then directed through the intake tube into the engine's throttle body for a guaranteed power gain. The intake tube has an attractive blue powder-coat finish to match the car's badging and it accommodates the factory air pressure sensor. The oversized cone shaped air filter can be used for up to 100,000 miles before servicing is needed depending on driving conditions. This air intake is relatively easy to install usually in 90 minutes or less using existing factory mounting points. Installation can be done using common tools.
- Guaranteed to increase horsepower
- Designed to improve throttle response and engine sound
- Low restriction aluminum tube
- Easy to install, usually in 90 minutes or less
- Filter lasts up to 100,000 miles before service is required
- Replaces stock air intake system
- Washable and reusable lifetime air filter
- K&N Million Mile Limited Warranty
Information:
Associated products: RU-5163DK Air Filter Wrap, RU-5163 Universal Clamp-On Air Filter, 99-5000 Filter Care Service Kit Aerosol
Application Summary:
| Year |
Make/Model |
| 2016-2018 |
Ford Focus |
| Attributes |
| Air Box Included |
No |
| Air Filter Color |
Red |
| Air Filter Element Washable |
Yes |
| Air Filter Material |
Cotton Gauze |
| Air Filter Outlet Shape |
Round |
| Air Filter Washable |
Yes |
| Alternate Part Number |
69-3539TB |
| ASIN |
B072N61XXY |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| California Restricted |
Not legal for sale or use in California |
| CARB EO Number |
D-269-70 |
| Clamp Color |
Natural |
| Clamp Color/Finish |
Natural |
| Clamp Material |
Stainless Steel |
| Clamp Quantity |
3 |
| Clamp Style |
Worm Gear |
| Clamps Included |
3 |
| Country of Origin (Primary) |
US |
| Coupler Color |
Black |
| Coupler Color/Finish |
Black |
| Couplers Included |
1 |
| Emission Code |
Legal US |
| Estimated Horse Power Gain |
33.01 HP @ 4904 RPM |
| Estimated Horsepower Gain |
33.01 HP @ 4904 RPM |
| Estimated Torque Gain |
31 lbft |
| Filter Color |
Red |
| Filter Material |
Cotton Gauze |
| Harmonized Tariff Code (Schedule B) |
8421310000 |
| Hazardous Material Code |
N |
| Horse Power Increase |
33 HP |
| Intake Pipe Color |
Candy Blue Powder Coating |
| Intake Pipe Color / Finish |
Candy Blue Powder Coating |
| Intake Pipe Material |
Aluminum |
| Intake Pipe Ports |
All intake tube ports needed for the specified applications are included |
| Item Weight |
9.400 lbs. (4.3 kg) |
| Life Cycle Status Code |
Available to Order |
| Mass Air Flow Sensor Adapter Included |
No |
| Mass Air Flow Sensor Included |
Mass Air Flow Sensor Adapter Included When Required |
| Mounting Hardware Included |
Yes |
| NAFTA Preference Criterion Code |
B |
| Oil Included |
Yes, Filter Is Pre-Oiled |
| Package Material |
Corrugated |
| Package Type |
Box |
| Product Box Height |
12.5 in (318 mm), 12.500 in. (318mm) |
| Product Box Length |
22.25 in (565 mm), 22.250 in. (565mm) |
| Product Box Width |
14.25 in (362 mm), 14.250 in. (362 mm) |
| Product Style |
69 Series Typhoon Kits |
| Replacement Filter |
RU-5163 |
| RPM |
4904 |
| SDR Required Flag |
N |
| Standard Pack |
1 |
| Street Legal |
No |
| Street Legal In All US States |
No, Legal for use in all 50 states. |
| System Type |
Complete Cold-Air Intake System |
| TUV Approved (Europe) |
No, No |
| Warranty |
No-Hassle Lifetime Limited |
| Weight |
9.4 lb (4.3 kg) |
| GTIN |
00024844365255 |
